Front Hub Motor
Based on the riding experience generated by our very sensitive torque sensor, bringing you the ultimate riding experience: quiet, light, efficient and as individual as your lifestyle.
- Light – only 1,5 kg
- Very small
- Noise optimized
| Model NO. | M060 Front Hub Motor |
|---|---|
| Rated Voltage (DC V) | 36 |
| Rated Power (W) | 250 |
| Shell Outer Diameter (mm) | 80 |
| Spoke Hole Center Distance (mm) | 89 |
| Weight (kg) | 1.5 |
| Motor Position | Front Wheel |
| Brake Type | Disc Brake |
| OLD (mm) | 102 |
| Way Out | End Face Outlet, Left |
| Wheel Size | 700C~16“ |
| System Efficiency | ≥80% (26“) |
| Max Torque (Nm) | ≥35 |
| No load Speed (rpm) | 245 (26“) |
| Rated Speed (rpm) | 220 (26“) |
| Reduction Ratio | 12.2 |
| Number of Speed Magnets | 6 |
| Noise (dBA) L=1m | ≤55 |
| Operating temperature (°C) | -20°C~45°C |
| Dustproof And Waterproof Rating | IP65 |
| Salt Spray Level (H) | 72 |
| Certification | EN 15194/ROHS |
